Bobcat E50z Mini Excavator - Export Technical Specifications

1. General Machine Data

• Manufacturer: Bobcat Company

• Model: E50z (Zero Tail Swing)

• Machine Type: Compact Hydraulic Excavator

• Year of Manufacture: [Current Year]

• Country of Origin: Belgium (EU manufactured)

• Compliance: CE Marked, EU Stage V Emissions

2. Dimensional Specifications

• Operating Weight: 5,000 kg

• Shipping Dimensions:

  • Length: 5,570 mm

  • Width: 1,990 mm

  • Height: 2,640 mm

• Ground Clearance: 380 mm

• Transport Width: 1,990 mm (with standard tracks)

3. Powertrain System

• Engine: Kubota V3307-CR-TE4

• Engine Type: 4-cylinder turbocharged diesel

• Displacement: 3.318 L

• Rated Power: 36.5 kW (48.9 hp) @ 2,200 rpm

• Fuel Capacity: 90 L

• Cooling System: Liquid-cooled with viscous fan

4. Hydraulic System

• Main Pump Flow: 2 x 56 L/min

• System Pressure: 34.3 MPa

• Control System: Load-sensing hydraulics

• Auxiliary Circuits: Standard dual-line hydraulics

5. Performance Metrics

• Max Digging Depth: 3,830 mm

• Max Reach: 6,240 mm

• Bucket Digging Force: 42 kN

• Arm Digging Force: 28 kN

• Travel Speed: 4.8 km/h

6. Undercarriage System

• Track Type: Steel-reinforced rubber

• Standard Track Width: 450 mm

• Track Length on Ground: 2,220 mm

• Ground Pressure: 36 kPa

7. Attachments & Tools

• Standard Bucket Capacity: 0.18 m³

• Quick Coupler: Bobcat Tach-All system

• Auxiliary Hydraulic Flow: 60 L/min

• Available Attachments: 20+ Bobcat-approved options

8. Operator Station

• ROPS/FOPS: ISO 12117-2 compliant

• Control System: ISO pattern joysticks

• Display: Advanced LCD monitor

• Seat: Air suspension with heating option

9. Export Documentation

• HS Code: 8429.52.00

• CE Documentation: Full technical file

• Noise Certification: 104 dB(A)

• Dangerous Goods: Non-hazardous declaration

• Export Packaging: Weatherproof steel frame

10. Shipping & Logistics

• Container Compatibility: 40' HC container

• Loading Capacity: 1 unit per container

• Gross Shipping Weight: 5,200 kg

• Lifting Points: Certified lifting eyes

11. Warranty & Support

• Base Warranty: 24 months/2,000 hours

• Service Network: 1,200+ global dealers

• Parts Availability: 85% common parts stock

12. Target Applications

• Urban construction

• Utility installation

• Landscape development

• Road maintenance

• Agricultural applications

13. Competitive Advantages

• Best power-to-weight ratio in class

• 12% more efficient hydraulics vs competitors

• 360° visibility design

• Integrated attachment control system

14. Compliance Certificates

• EU Machinery Directive 2006/42/EC

• EMC Directive 2014/30/EU

• Noise Emission Directive 2000/14/EC

• REACH Compliance Statement

15. Optional Export Features

• Cold weather package (-30°C)

• Desert cooling package (+50°C)

• Right-hand control configuration

• Local language instrumentation

This specification meets all requirements for:

• Customs clearance documentation

• Technical tenders

• Buyer evaluation

• Import licensing

• Equipment registration
