Bobcat E35 Compact Excavator - Technical Export Specifications

1. Basic Machine Parameters

• Model: E35

• Machine Type: Compact Hydraulic Excavator

• Year of Manufacture: [Current Year]

• Country of Origin: USA

• Operating Weight: 3,550 kg (7,826 lbs)

• Shipping Weight: 3,750 kg (8,267 lbs) including standard attachments

2. Dimensions & Transport

• Transport Width: 1,770 mm (5'10")

• Transport Length: 4,490 mm (14'9")

• Transport Height: 2,540 mm (8'4")

• Ground Clearance: 310 mm (12.2")

• Track Width: 300/400/500 mm (adjustable)

3. Power System

• Engine Model: Kubota V2403-M-DI-E4

• Engine Type: 4-cylinder liquid-cooled diesel

• Displacement: 2.434 L

• Net Power: 24.8 kW (33.3 hp) @ 2,500 rpm

• Fuel System: Direct injection

• Cooling System: Pressurized radiator with fan

• Emissions Compliance: EPA Tier 4 Final/EU Stage V

4. Hydraulic System

• Main Pump Type: Variable displacement axial piston pump

• System Pressure: 24.5 MPa (3,553 psi)

• Pump Flow: 2 x 32 L/min (2 x 8.5 gpm)

• Control Valve: 6-spool load-sensing

• Swing Motor: Axial piston type

5. Performance Metrics

• Max Digging Depth: 3,670 mm (12'0")

• Max Reach at Ground Level: 5,870 mm (19'3")

• Bucket Digging Force: 32.2 kN (7,238 lbf)

• Arm Digging Force: 18.6 kN (4,181 lbf)

• Blade Force: 18.2 kN (4,092 lbf)

6. Undercarriage

• Track Shoe Width: 300 mm standard (400/500 mm optional)

• Track Gauge: 1,390 mm (4'7")

• Ground Pressure: 34.3 kPa (4.98 psi)

7. Attachments & Compatibility

• Standard Bucket Capacity: 0.11 m³ (0.14 yd³)

• Quick Coupler: Bobcat Tach-All compatible

• Auxiliary Hydraulics: Standard (2-line)

• Available Attachments: Breakers, augers, tilt buckets, grapples

8. Operator Environment

• ROPS/FOPS Certified Cab: ISO 12117-2, ISO 3449

• Climate Control: Optional A/C and heating

• Instrumentation: Digital LCD monitor

• Seat: Suspension seat with adjustable armrests

9. Export Compliance & Documentation

• Emissions Certification: EPA Certificate of Conformity included

• CE Marking: Full compliance documentation

• Noise Level: 104 dB(A) certified

• Dangerous Goods: Non-hazardous for shipping

• HS Code: 8429.52.00 (Track-type excavators)

10. Packaging & Shipping

• Export Packaging: Weatherproof steel frame crate

• Loading Requirements: Top lift only

• Container Fitment: Fits 40' open top container

• Documentation Package:

  • Commercial invoice

  • Packing list

  • Certificate of Origin

  • CE Declaration of Conformity

  • Operator's manual (English/Spanish)

  • Parts catalog

11. Warranty & Service

• Standard Warranty: 24 months or 2,000 hours

• Service Intervals: 500 hour maintenance cycles

• Global Support: Bobcat dealer network coverage

12. Target Markets & Applications

• Primary Export Markets: EU, Middle East, Southeast Asia, Latin America

• Typical Applications:

  • Urban construction

  • Utility installation

  • Landscape development

  • Agricultural use

  • Road maintenance

13. Competitive Advantages

• Best-in-class digging forces for size category

• Advanced hydraulic efficiency (15% better than competitors)

• Global parts availability

• Superior stability with optimized counterweight design
